小型滾筒混凝土攪拌機具體怎么操作?
小型滾筒混凝土攪拌機的具體操作方法。滾筒式混凝土攪拌機主要用于攪拌塑性和半塑性混凝土,是民用混凝土攪拌機的一種,與爬梯式混凝土攪拌機不同,其攪拌方法是把混合料放在一個旋轉的攪拌鼓內,跟著攪拌鼓的旋轉,鼓內的葉片把混合料提高到必定的高度,然后靠自動自在撒落下來,由此循環往復直攪拌均勻,具體的操作方法是:
Concrete operation method of small drum concrete mixer. Drum type concrete mixer is mainly used for mixing plastic and semi plastic concrete. It is a kind of civil concrete mixer. Different from ladder type concrete mixer, its mixing method is to put the mixture in a rotating mixing drum. With the rotation of the mixing drum, the blades in the drum raise the mixture to a certain height, and then automatically sprinkle it down, thus recycling The specific operation method is as follows:
1、對某些需求挖設上料斗地坑的攪拌機,其坑口周圍應墊高夯實,以防地面水流入坑內,上料軌道架的底端支承面應夯實或鋪磚、架的后邊亦須用木料加以支承,防止工作時軌道變形。
1. For some mixers that need to excavate the hopper pit, the pit mouth should be padded and compacted to prevent the ground water from flowing into the pit. The bearing surface of the bottom end of the loading track frame should be tamped or paved with bricks, and the rear edge of the rack should also be supported with wood to prevent the track deformation during operation.
2、混凝土攪拌機發起后,應使攪拌筒到達正常轉速后進行上料,上料后要及時加水;添加新料有必要先將攪拌機內原有的混凝土全部卸出后才干進行,不得半途停機或滿載荷時起動攪拌機,反轉出料者在外。
2. After the concrete mixer is started, the mixing drum shall reach the normal speed before loading, and water shall be added in time after loading. It is necessary to unload all the original concrete in the mixer before adding new materials. It is not allowed to start the mixer when the mixer is stopped halfway or under full load, and the reverse discharging is outside.
3、在混凝土攪拌機運用中,切勿使砂石落入機器工作有些中去,防止使工作部件卡住損壞,上料斗提高后,斗下不能有人通過或停留,防止制動器失靈發生意外事端,如必在斗下修理或進行整理工作時,強行停機并將上料斗用保險鏈條拉牢。
3. In the operation of concrete mixer, do not let sand and gravel fall into the operation of the machine to prevent the working parts from being jammed and damaged. After the upper hopper is raised, no one can pass or stay under the bucket, so as to prevent accidents caused by brake failure. If it is necessary to repair or arrange under the bucket, stop the machine by force and pull the upper hopper firmly with safety chain.
4、新機運用前應按照微型混凝土攪拌機運用說明書的要求,對各體系和部件逐項進行查驗及必要的試工作,空車工作,查看攪拌筒或攪拌葉的滾動方向,各工作設備的操作、制動,供認正常,方可工作。
4. Before the new machine is put into use, all systems and components shall be inspected item by item and necessary trial work shall be carried out according to the requirements of the operation manual of the micro concrete mixer. The machine can work only after the rolling direction of the mixing drum or mixing blade is checked, and the operation and braking of all working equipment are normal.
